Features:
• MPN: A-3034
• 650-watt drive motor, 2,200-watt lift motor
• Forks are adjustable to fit most pallets
• Curtis (US Brand) Controller
• Use GEL battery free to maintain
• Both sides of button for lifting and lowering operation
• Multi-function display shows the working hours, battery status and low-voltage protection
• Smooth rolling polyurethane wheels. 180° steering arc
• 110V Built-in Charger
• 6 hours service per charge: two 12-volt, 105 Ah rechargeable GEL batteries
• Not explosion proof
• This forklift is designed to be used on flat ground, avoiding uneven grounds with potholes or large ramp
• Temperature range of working environment below 50˚F~104˚F
• Fully charge battery before use to avoid damaging cells
• Charger plugs into standard 110V-120V outlets
• Charge the forklift once a month even it's not in use
Specifications:
• SKU: A3034
• Load Capacity: 2,640 lbs
• Battery Capacity: 24V/105AH
• Height Raised: 98''
• Wheel Diameter: 7.7"
• Overall Length: 70"
• Recommended Aisle Width: 89.7"
• Turning Radius 58.6":
• Mast Height Lowered: 74.6''
• Mast Height Raised: 122''
• Load center: 23.6"
• Ground Clearance: 1.38"
• Fork height, Lowered: 3.15''
• Adjustable Forks: 7.8"-31.5"
• Thickness: 1.3"
• Width: 3.9"
• Length: 42"
• Height: 4.1"
• Adjustable range: 44" - 60"
• Travel speed (laden/unladen): 2.8/3.1mph
• Lifting speed (laden/unladen): 3.5/5.5inch/s
• Lowering speed (laden/unladen): 4.7/3.9inch/s
• Weight: 1,250
